Features:
- PID controller provides high temperature stability as well as warning and safety functions
- Incorporates latest-generation components for highly reliable refrigeration and pump performance
- Easy to operate and install
- Precise temperature stability for repeatable result
- Space saving design uses minimal space
- Can be used for open bath applications
Applications:
- Ideal for precise temperature control of external devices, such as a distillation apparatus, automatic able flash point apparatus, fermenter, heat exchangers, jacketed reaction vessels, material testing, analytical instrumentation, condensers and mini plant installation
- Designed to circulate external closed loop applications
|
SPECIFICATIONS
|
|
Temperature Range & Model
|
Temperature Range
|
Model
|
|
-80°C to -20°C
|
Floor Model only
|
|
-40°C to Ambient
|
Floor Model / Table Top
|
|
-20°C to Ambient
|
Floor Model / Table Top
|
|
Temperature Controller
|
Microprocessor based PID Controller with RTD Sensor(PT-100)
|
|
Display Resolution
|
Available in two Resolution
|
|
0.1°C
|
0.01°C
|
|
Control Accuracy
|
±0.20C
|
±0.02°C
|
|
Refrigeration System
|
Compressor
|
Hermetically Sealed Compressor
|
|
Condenser
|
Fin & Tube type Air-Cooled Condenser
|
|
Cascade System
|
For below -40°C ranges
|
|
Refrigerant
|
Temp Range
|
Refrigerant used
|
|
-80°C to -20°C
|
R404a and R508b
|
|
-40°C to Ambient
|
R404a
|
|
-20°C to Ambient
|
R134a
|
|
Pump Cum Stirrer
|
Maximum Flow
|
Maximum Head
|
|
3 to 4 LPM(at zero head)
|
1 meter
|
|
8 to 10 LPM(at zero head)
|
1.5 meters
|
|
Cabinet Material
|
Exterior
|
CRCA with Powder Coated
|
|
Interior
|
Duly polished 304 grade Stainless Steel
|
|
Capacity in Litres
|
Lid Opening
|
Length
|
Width
|
Depth
|
|
12 Ltrs
|
200 x 200
|
300
|
200
|
200
|
|
Custom Built sizes are also available on request
|
|
Power Source
|
230V, 50Hz Single Phase
|
|
Optional
|
Duly polished 304 grade Stainless Steel exterior cabinet
|
Due to constant upgradation, specifications & features are subject to change without notice.
